Outdoor/INdoor FTTH drop cable ftth fiber optic cable


Product Construction


Fiber:


250µm colorfiber
Fiberglass reinforced plastic (FRP) or Steel Wire.


Self-supported Member:


Steel Wire


Outer Jacket:


UV and Flame resistant LSZH


 Features


Compact, soft, flexible, easyto install.



 Applications



Used in access network oras access cable from outdoorto indoor
in customer premises network.
Used as access building cable in premises distribution system,especially used in indooror outdooraerial access cabling.





  Optical Characteristics

Fiber Type             Attenuation Overfilled launch BandwidthEffective Modal Bandwidth10GB/S Ethernet link length Min Bending Radius
 Conditions 1310/1550nm 850/1300nm    850/1300nm      850nm     850nm
 Unit     dB/km    dB/km    MHZ.km     MHZ.km          m        mm
 G652D  0.36/0.22



        16
 G657A1  0.36/0.22



        10
 G657A2  0.36/0.22



        7.5
 50/125
   3.0/1.0     ≥500/500

        30
 62.2/125
   3.0/1.0     200/500

        30
 OM3
   3.0/1.0     ≥1500/500      ≥2000      ≥300        30
 OM4
   3.0/1.0     ≥3500/500      ≥4700      ≥550        30
 B1-OM3
   3.0/1.0    ≥1500/500      ≥2000      ≥300        7.5
 B1-OM4
   3.0/1.0     ≥3500/500      ≥4700       ≥550        7.5



  Structure and Technical Specifications

  Fiber Count

   Cable Diameter

         (mm)

   Cable Weight

        (kg/km)


   Tensile Strength

       (N/100mm)

         Crush Resistance

                (N/100mm)

 Short Term Long Term   Short Term  Long Term
1-4  5.2*2.0  18600300 2200

  1000

6-123.0*9.02712006001100

500

Note :1.This datasheet can only be a referance,but not a supplement to the contract,Please contact our sales people for

          more information.

         2.The cable core use the colored coating fiber of 250μm.

         3.The tensile and crush of the cable are accordance with the values in the table when the strength member of  FRP              and Steel are used



  We produce and test cable comply with following standard

Mechanical Performance

Max Tension Performance

IEC 60794–1-2-E

Max. Operation Tension

IEC 60794–1-2-E1

Crush Test

IEC 6079 –1-2-E3

Impact Test

IEC 60794–1-2-E4

Repeated Bending

IEC 60794–1-2-E6

Torsion Test

IEC 60794–1-2-E7

Cable bend

IEC 60794–1-2-E11A

Attenuation Coefficient

ITU-T G.652

Structural Test

IEC-60793-1-20

Environmental Performance

Temperature Cycling

IEC 60794–1-2-F1

Water Penetration

IEC 60794–1–2-F5B

Filing Compound Flow

IEC 60794-1-E14
